Vacuum Packaging Machine 25 Kg / 150 Kg

25 kg Double Chamber Hinged Doors Vacuum Packaging Machine

25 kg Double Chamber Hinged Doors Vacuum Packaging Machine

Vacuum Packaging Machine

Model Name : 20 kg Straight Chamber vacuum packing machine.

Vacuum Chamber : Width 590mm x Depth 200mm x Height 790mm.

Overall size : Width 780mm x Depth 1200mm x Height 910mm.

Gross weight : 250 kg, Net weight with pump approx.: 350 kg.

Power : Maximum 3500 watts.

Construction : Complete SS 304.

Vacuum Pump (Busch - Made in Germany) : 666 LPM/ 40 cum³/ hr, single stage for faster vacuum. Oil re-circulating hence requires less oil, low noise (< 75 db), no emission of oil mist.

Lid : SS 304.

Sealing bar size : One sealing bar 580mm.

Moulds : 20kg ss mould with machine

Gas purging facility : By default.
We make customize machines as per customers requirement, quantity no bar.


150 kg Vacuum Packing Machine

150 kg Vacuum Packing Machine

Vacuum Packaging Machine

Model Name : 150 kg T Type Vacuum Packing machine

Overall size of the machine : 1010 Width x 1900 Depth x 1900 Height.

Net weight with pump approx : 1300 kg

Power : Maximum 10 KW.

Construction : Chamber, Chamber plate & moulds SS 304 other structure MS powder coated.

Vacuum Pump : 5000 LPM/ 300 cum³/ hr, single stage for faster vacuum. Oil re-circulating hence requires less oil, low noise (< 76 db), no emission of oil mist.

Lid : SS 304 with 16 mm toughened glass window.

Sealing bars size : One sealing bar 920 mm. Useable length: 870

Cycle Time : Vacuum to Level of 99.9mm Hg -50 Seconds, Sealing: 2Seconds, Air Entrance :10 Seconds, Total: 62 Seconds

Moulds : Made of SS 304, 2 nos. of size 520 Width x 345 Depth x 1300 mm Height

Bag holder : This also works as gas purging nozzle. Bag holder maintains the sealing area of the bag flat and straight before sealing to achieve wrinkle free sealing. Micro wrinkles can damage the vacuum in pack when bag is out in ambient atmosphere. We make customize machines as per customers requirement, quantity no bar.
